The fully symmetrical optical system measures sample and reference simultaneously for ultimate accuracy, precision and baseline flatness. Long term stability is at least ten times better than single beam systems. Coated optics for long life.
Variable Optical Bandwidth
The CE 9500 offers variable optical bandwidth from 0.5mm to 4mm. This range covers all the more exacting applications where either high optical resolution or maximum energy throughput is required.
Method Operation and Storage
Up to 100 sets of instrument parameters, including concentration curves may be stored, security code protected. When recalled, instrument parameters are automatically set, avoiding errors.
Alpha Numeric Entry and Assay Program
A full Alpha Numeric facility is provided for formula entry and documentation for GLP. Assay formula entry with Assay Program is rapid and calculations using many wavelengths may be made at high speed with fully documented results.
Software Enhancement By E-SEF
E-SEF - Encoded Software Enhancement Facility - allows software modules to be enabled using encoded numbers provided by telephone, fax or E-mail. Software requirements may be tailored, at any time, as required.
Data Storage and Protection
Data, including 100 spectra, concentration curves , kinetics and time course plots may be stored in safe memory, security code protected against tamper or deletion using a four digit password.
Reprocessing
Scans, time course plots, and reaction curves may all be reprocessed to any required format on the display screen and then plotted on the integral or an external printer.
Photomultiplier Detector
A high performance end window photomultiplier is used in all instruments for best possible accuracy and optimum performance in narrow bandwidth, or energy limited applications, eg turbid sample measurement.
Performance Validation
Software and certified standards enable wavelength accuracy, Absorbance accuracy, bandwidth etc. to be validated. A timed and dated report includes the serial number of the instrument.
Powerful Quantification
Many quantitative methods are available including band area computation with background correction, differencing and stripping of spectra, wine and colour assays, mathematical calculations between several wavelengths, protein and DNA assays.
Assay Program
Assay formulae requiring measurements at up to 10 wavelengths may be entered rapidly. Programming for computation is automatic at entry without user intervention. Automatic sequences may be set for multi-sample assays and may be stored as methods.
Curve and Line Fitting
A straight line, quadratic or cubic concentration curve may be fitted to up to 30 standards, with or without an intercept at the origin. Standards may be deleted and replaced and a new curve fitted.
Reaction Kinetics
Single cell kinetic measurements are possible with plots and data displayed on screen. Data may be reprocessed, regression analysis applied and curves stored, security code protected against tamper or deletion.
Multi-Cell Reaction Kinetics
Up to four or six cells are automatically measured with all reaction curves displayed on screen. Each curve may be selected for processing with the results of regression analysis printed.
Multi Wavelength and Bio Assays
Assays are provided using either two or three wavelengths. A wine colour assay is provided. Assays for Warburg and Christian, Lowry, Bradford, Biuret and BCA methods are also available.
Band Area and Height Computation
Band areas with correction for sloping background absorption are readily quantified, with all details and construction displayed. Band areas may also be computed for derivative spectra to facilitate difficult quantification.
Cell Program
Using the various cell changers, measurements may be made on up to 4, 6 or 8 cells at a single wavelength with cycle time and number of cycles entered by the operator. A cell and wavelength program may be combined.
Wavelength Program
Measurements may be programmed for 10 different operator selected wavelengths with the cycle time and number of cycles selected by the operator. A wavelength and cell program may be combined.
Scanning
Double Beam Wavelength Scans
Scans at up to 4000nm/min are presented on screen or printed with all peaks annotated with wavelength and Absorbance. Tables are also presented listing all peaks and troughs with values.
Display Scrolling
Use of the display scrolling facility enhances the effective screen size and enables spectra and data up to 550mm wide, 6 screen widths, to be viewed. The last eight scans are automatically retained for recall by entering their scan sequence number and may be reprocessed, overlayed or transferred to protected memory for future recall.
Overlayed Spectral Scans
Up to six scans, including stored scans, may be overlayed, with or without offsets for convenient comparisons or further manipulation.
Difference Spectra
New wavelength scans or scans from store may be presented on screen and the difference spectra produced. The scans may be normalised enabling spectral stripping to reveal impurities or additives.
Derivative Spectra
Derivative spectra, up to sixth are readily produced, with selectable smoothing, either alone or superimposed on the fundamental, with or without an offset. Scaling is automatic with all peaks and troughs quantified.
Scan Storage
Up to 100 spectra may be stored in 10 safe memory banks for future recall. Each spectrum is automatically allocated a recall number, when stored, and may be security code protected against tamper or deletion.
Programmed Scans
Automatic scans, single or repeat may be made of a cell program of up to 4, 6 or 8 cells. A programmed sequence of scans may also be made of a single sample.
Time Course Plots
Changing samples or flows may be examined and displayed by making a time course plot. Data may be reprocessed and stored, security code protected, with an automatically assigned recall number.
Sampling
Cells and Flowcells
As well as 10mm cells and flowcells, holders are available for rectangular and cylindrical cells up to 100mm pathlength. A microsampling system measures to 50µl or below. Third party nano cells may also be used.
Turbid Sample Measurements
A turbid sample optical system enables the measurement of heavily scattering samples, which would otherwise be difficult or impossible to measure. 10mm cells, films or solid samples may be measured.
Automatic Cell Changers
Automatic changers are available for 4, 6 or 8 cells, providing rapid sample changing or the facility for full programming.
Sipette Sampling
Samples down to 300 microlitres may be measured in a 10mm cell. Sampling is under control of the instrument's microprocessor system. Samples may be saved or pumped to waste.
Sample Temperature Control
Water and thermoelectric temperature control are available for single cells and automatic cell changers. Temperature is set from the control panel and displayed on the screen.
Batch Sampling
Automatic batch sampling for up to 100 samples is available. The pump fits within the sample compartment and volume etc is set from the control panel and displayed on screen. Batch number entry is provided.
Dissolution Testing
Versions of the instruments fitted with a special cell compartment with piping port, are available for dissolution testing using Cecil TD software and a PC. Six and eight cell changers are available.
Specular Reflectance
Special accessories enable specular reflectance measurements to be made. Both fixed angle and variable angle reflectance accessories are available. The latter is particularly useful for film thickness measurements.
Fluorescence and Gel Scanning
Using the fluorescence accessory quantitative assays are possible. When required the excitation wavelength may be scanned. A gel scanner enables 100mm gels and films to be measured.
================================================
雙光束光學系統
完全對稱的光學系統可以同時測量樣品和參比的最終準確度，精密度和基線平直度。長期穩定性比單波束系統更好的至少10倍。鍍膜光學，使用壽命長。
可變光帶寬
該CE 9500提供了可變的光帶寬從0.5mm到4毫米。這個范圍涵蓋了所有的更加嚴格的應用場合是必需的或高光學分辨率或最高能量的吞吐量。
方法操作和儲存
高達100套的儀器參數，包括濃度曲線可以存儲，安全代碼的保護。當回憶說，儀器參數都自動設置，避免錯誤。
字母數字輸入和分析程序
一個完整的字母數字設備提供了一種用于GLP公式輸入和文檔。試驗配方條目與測定程序是快速和使用多個波長的計算可以由高速用完整的文檔的結果。
軟件增強通過E- SEF
E- SEF - 編碼軟件增強基金 - 允許使用通過電話，傳真或電子郵件提供的編碼數字被激活的軟件模塊。軟件要求可定制的，在任何時候，根據需要。
數據存儲和保護
數據，其中包括100光譜，濃度曲線，動力學和時間進程曲線可以存儲在安全的存儲，使用一個四位數的密碼安全密碼保護，防止篡改或刪除。
后處理
掃描，時間過程圖，并反應曲線可以全部進行再加工，以在顯示屏幕上的任何所需的格式，然后繪制在積分或外部打印機。
光電倍增管檢測器
高性能端窗光電倍增管是用在為最佳的精確度和最佳的性能在窄帶寬，或能量受限的應用，如渾濁樣品測量所有儀器。
性能驗證
軟件和認證標準，使波長準確度，吸光度精度，帶寬等進行驗證。一個定時及于報告包括儀器的序列號。
強大的定量
許多定量方法可供選擇，包括帶面積計算與背景校正，差分和光譜，酒和彩色分析，幾個波長，蛋白質和DNA檢測的數學計算的剝離。
試驗計劃
試驗配方需要測量高達10個波長可以迅速進入。編程計算是自動的，無需用戶干預項目。自動序列可用于多樣品分析和設置可被存儲為方法。
曲線和擬合線
直線，二次或三次濃度曲線可裝配到高達30標準，使用或不使用截距在原點。標準可能會被刪除并替換和新的曲線擬合。
反應動力學
單細胞動力學測量是可能的情節和畫面上顯示的數據。數據可能會被重新處理，回歸分析應用和曲線存儲，安全代碼保護，防止篡改或刪除。
多細胞反應動力學
多達四個或六個細胞與屏幕上顯示的所有反應曲線自動測量。每條曲線可用于處理被選擇與回歸分析印刷的結果。
多波長及生物測定
使用兩個或三個波長的光被提供的檢測。提供一個葡萄酒的顏色檢測。用于檢測華寶和基督教，洛瑞，布拉德福德，縮二脲和BCA方法也可提供。
帶面積和高度計算
與校正傾斜的背景吸收帶區域容易量化，并顯示所有的細節和建設。帶區域也可以被計算為微分光譜，以便難以定量。
細胞程序
使用各種細胞變換器，測量可以由多達4或6或8個細胞在含有周期時間和由操作者輸入的周期數的單一波長。的細胞和波長程序可被組合。
波長程序
測量可以被編程為10個不同的操作員所選擇的波長的周期時間和由操作者選定的周期數。波長和細胞程序可被組合。
掃描
雙光束波長掃描
掃描速度高達4000nm/min呈現在屏幕上或印有注釋的波長和吸光度所有峰。表中還提出，列出所有的波峰和波谷與價值觀。
滾動顯示
使用顯示滾動設施的提高有效屏幕尺寸，使光譜和數據高達550毫米寬， 6屏幕的寬度，來看待。八強掃描通過輸入其掃描順序號自動保留和召回可能被再加工，重疊或轉移到受保護的內存以備將來調用。
重疊光譜掃描
多達六個的掃描，包括存儲的掃描，也可以重疊，帶或不帶偏移量為便于比較，或進一步的操作。
差譜
從存儲新的波長掃描或掃描可以被呈現在屏幕上，所產生的差示光譜。該掃描可以被歸一化使得頻譜剝露出的雜質或添加劑。
導數光譜
微分光譜，最多第六易于生產的，具有可選的平滑處理，無論是單獨或疊加在基本的，帶或不帶偏移量。縮放是自動與量化所有的波峰和波谷。
掃描存儲
高達100光譜可以存儲在10安全存儲銀行以備將來調用。每個光譜是自動分配的召回?cái)?shù)，存儲時，也可以安全碼保護，以防止篡改或刪除。
編程掃描
自動掃描，單次或重復可以由一個單元程序的最多4個， 6個或8個細胞。掃描的編排順序也可以由一個單一的樣本。
時間課程地塊
更換樣品或流量可檢測并顯示通過做一個時間過程的情節。數據可能會重新處理和存儲，安全代碼保護自動分配的召回?cái)?shù)量。
采樣
細胞和測量管
以及10毫米細胞和測量管，支架可用于矩形和圓柱形電池可達100mm光程。一個微量進系統的措施， 50μL或以下。第三方納米細胞也可使用。
渾濁的樣品測量
混濁樣品光學系統使大量散射樣品，否則會難以或無法測量的測量。 10毫米細胞，膜或固體樣品可以進行測量。
自動換電池
自動換可用于4,6或8個細胞，提供快速樣品更換或設施進行全面編程。
Sipette采樣
樣品下降到300微升可以以10mm比色皿進行測定。抽樣是根據儀器的微處理器系統的控制權。樣品可以保存或抽浪費。
樣品溫度控制
水和熱電溫度控制可用于單個細胞和細胞自動換。溫度從控制面板中設置和顯示在屏幕上。
批量采樣
自動批量采樣多達100個樣品是可用的。樣品室中的泵適合，體積等從控制面板中設置并在屏幕上顯示出來。提供批號條目。
溶出度測試
配有特殊的細胞室與配管口的工具版本，可使用塞西爾TD軟件和PC溶出度測試。六到八個細胞兌換服務。
鏡面反射
特殊配件使鏡面反射率測量作出。兩個固定角度和變角反射附件可供選擇。后者是用于薄膜厚度測量時特別有用。
熒光和凝膠掃描
使用熒光附件的定量分析是可能的。當需要的激發波長可以被掃描。凝膠掃描儀能夠百毫米凝膠和薄膜進行測量。
